ADS5263IRGCT

Description

Quality information
Rating
Catalog
RoHS
Yes
REACH
Yes
Lead finish / Ball material
SN
MSL rating / Peak reflow
Level-3-260C-168 HR
Quality, reliability
& packaging information
View or download
Additional manufacturing information
View
Export classification
*For reference only

US ECCN: 3A001A5A5
More ADS5263 information
Parametrics
Technical documentation
Design & development
Support & training
Packaging information
Package | Pins
VQFN (RGC) | 64
Operating temperature range (°C)
-40 to 85
Package qty | Carrier
250 | SMALL T&R
Features for the ADS5263
Maximum Sample Rate: 100 MSPS
Programmable Device Resolution
Quad-Channel, 16-Bit, High-SNR Mode
Quad-Channel, 14-Bit, Low-Power Mode
16-Bit High-SNR Mode
1.4 W Total Power at 100 MSPS
355 mW / Channel
4 Vpp Full-scale Input
85-dBFS SNR at fin = 3 MHz, 100 MSPS
14-Bit Low-Power Mode
785 mW Total Power at 100 MSPS
195 mW/Channel
2-Vpp Full-Scale Input
74-dBFS SNR at fin = 10 MHz
Integrated Clamp (for interfacing to
CCD sensors)
Low-Frequency Noise Suppression
Digital Processing Block
Programmable FIR Decimation Filters
Programmable Digital Gain: 0 dB to 12 dB
2- or 4-Channel Averaging
Programmable Mapping Between ADC Input
Channels and LVDS Output Pins–Eases Board
Design
Variety of Test Patterns to Verify Data Capture by
FPGA/Receiver
Serialized LVDS Outputs
Internal and External References
3.3-V Analog Supply
1.8-V Digital Supply
Recovers From 6-dB Overload Within 1 Clock
Cycle
Package:
9-mm × 9-mm 64-Pin QFN
Non-Magnetic Package Option for MRI
Systems
CMOS Technology
Description for the ADS5263
Using CMOS process technology and innovative circuit techniques, the ADS5263 is designed to operate at low power and give very high SNR performance with a 4-Vpp full-scale input. Using a low-noise 16-bit front-end stage followed by a 14-bit ADC, the device gives 85-dBFS SNR up to 10 MHz and better than 80-dBFS SNR up to 30 MHz.

ADS5263 has a 14-bit low power mode, where it operates as a quad-channel 14-bit ADC. The 16-bit front-end stage is powered down and the part consumes almost half the power, compared to the 16-bit mode. The 14-bit mode supports a 2-Vpp full-scale input signal, with typical 74-dBFS SNR. The ADS5263 can be dynamically switched between the two resolution modes. This allows systems to use the same part in a high-resolution, high-power mode or a low-resolution, low-power mode.

The device also has a digital processing block that integrates several commonly used digital functions, such as digital gain (up to 12 dB). It includes a digital filter module that has built-in decimation filters (with low-pass, high-pass and band-pass characteristics). The decimation rate is also programmable (by 2, by 4, or by 8). This makes it very useful for narrow-band applications, where the filters can be used to improve SNR and knock-off harmonics, while at the same time reducing the output data rate.

The device includes an averaging mode where two channels (or even four channels) can be averaged to improve SNR. A very unique feature is the programmable mapper module that allows flexible mapping between the input channels and the LVDS output pins. This helps to greatly reduce the complexity of LVDS output routing and can potentially result in cheaper system boards by reducing the number of PCB layers. Specification of device is over industrial temperature range of –40°C to 85°C.
